PARKER 512C, 2Q ANALOG DC DRIVE :
Isolated control circuitry, a host of user facilities and extremely linear control loop makes the 512C series 2-quadrant DC drives ideal for single motor or multi-drive low power applications. Designed for use on single phase supplies, the 512C is suitable for controlling permanent magnet or field wound DC motors in speed or torque control. It can be used open loopÃƒ¢Ã¢â€š¬Ã‚ with armature voltage feedback or with DC tacho feedback for enhanced regulation and speed range. Chassis mount IP00 rated, with output ratings up to 32A/10HP, typical applications include centrifugal fans and pumps, extruders and mixers, plus small paper converting machines.
Output Current Ratings:
4A / 8A / 16A / 32A
DC MOTOR SPEED CONTROLLER - DC512C SERIES
Overload: 150% for 60 seconds
Available Field Current: up to 3A DC.
0-40oC / 32-104oF
Up to 1000m ASL
Tachogenerator / - Armature Voltage Feedback
Speed / - Load / - Ramp Output / - Total Reference / - Reference Voltage Ã‚±10V
Run (Active) / - Stall Enable
Zero Speed / - Health
